Description
The Lincoln POWER MIG 262P Factory Demo represents an exceptional opportunity to acquire professional-grade welding technology at enhanced value without compromising on performance or capability. This premium wire-fed welding system delivers impressive versatility with its comprehensive process range including MIG, Pulsed MIG, and Flux-Cored applications, all supported by a robust 300 Amp maximum output capacity. Designed for demanding professional environments, the POWER MIG 262P excels in applications ranging from precision automotive bodywork to intensive fabrication projects where consistent performance and reliability are essential.
Compare to new Power MIG 262P – K5378-1
At the core of the POWER MIG 262P is Lincoln’s advanced digital control system featuring a vibrant 7-inch color LCD display that transforms the operator experience through enhanced communication and intuitive navigation. The system incorporates Lincoln’s groundbreaking Ready.Set.Weld, ArcFX, and Weld Set Memory technologies, providing unprecedented precision and consistency across all welding processes. The specialized aluminum pulse technology delivers superior results on both 4XXX and 5XXX series aluminum, eliminating the compromises typically associated with aluminum welding in conventional systems. The synergic control functionality simplifies operation by allowing users to set complete weld procedures with a single control adjustment, while the comprehensive memory recall system enables quick access to saved settings for maximum productivity.
The POWER MIG 262P features Lincoln’s rugged MAXTRAC industrial wire drive system, ensuring constant wire feed speed and consistent weld quality even in demanding applications. The system offers unmatched flexibility for aluminum welding with built-in electronics supporting three distinct feeding methods: Push Gun, Spool Gun, or Push-Pull Gun configurations. This adaptability makes the POWER MIG 262P an exceptionally versatile solution for professional welders across automotive, fabrication, education, and maintenance applications where performance and reliability are paramount. As a factory demo unit, this system has been thoroughly inspected and certified by Lincoln Electric to ensure proper operation while offering exceptional value for professional users seeking premium welding capability.
Key Features
- 7-Inch Color Display – Enhances communication between operator and machine.
- Aluminum Pulse Process – Welds 4XXX and 5XXX series aluminum for superior quality welding.
- Versatile wire-fed welding – Welds MIG, flux-cored, and pulsed MIG.
- 300 Amp Max Output- Perfect for autobody, light fabrication, education, and more.
- Memory Recall- Easily save and access memories with the enhanced UI.
- Synergic Control – Set weld procedures with one control.
- 3 Ways to Feed Aluminum – Electronics built in for all three methods using a Push Gun, Spool Gun or a Push-Pull Gun.
- Rugged MAXTRAC Industrial Wire Drive – Allows for constant wire feed speed and consistent welds.
What’s Included
- (1) POWER MIG 262P Welder
- (1) Quick Storage Accessories
- (1) 10 ft. Work Cable with Clamp
- (1) 10 ft. Power Cable with Plug
-
- Magnum® PRO 250L Welding Gun – 15 ft. (4.6 m) | K4530-2
- Deluxe Adjustable Gas Regulator and Hose Kit | K586-1
- Drive Roll Kit Combination 0.035 in. / 0.045 in. Solid Wire | KP1696-1
Specifications
Product Weights & Dimensions
| Dimensions (H x W x D) | 37.5 in x 18 in x 37.5 in (947.42 mm x 457.2 mm x 952.5 mm) |
| Net Weight | 250 lbs (113.4 kg) |
General Specification
| Machines Processes | Flux-Cored (FCAW) MIG (GMAW) Pulsed MIG (GMAW-P) |
| Open Circuit Voltage | 90V |
| Input Voltage | 208/230/460/575 |
| Input Current | 49.1/44/22.1/17.6 |
| Input Hertz | 60 |
| Input Phase | 1 |
| Input Power | 208/230/460/575/1/60 |
| Mode Icon | CV |
| Output Range | 5-300 amps |
| Polarity | DC |
Machine Technologies & Connections
| Amphenol Pins (type of connector) | 12 |
| Work Lead Connector Type | Lug |
Application
| Typical Application | Automotive General Fabrication Maintenance & Repair Repair Welding |
Warranty
| Warranty | 3 Years |
