Rhino Multi-Pro Tent Stake Driver – Compact, High-Impact Tool for Field Use (Model 301012)

Description

Free Shipping This item qualifies for free shipping anywhere in the continental United States.

Warranty 1 Year Warranty

Literature Owners Manual Parts Manual Service Kit Instructions Gas Post Driver Selection Chart Tent Stake or Square Chuck Install Instructions

For Professional Tent Installers

The Multi-Pro™ Tent Stake Driver has ergonomic features that enable the user to start the post driver with the standard side throttle, but then finish driving with the post driver holding the additional top throttle.

• Comes with Rhino™ Tent Stake Chuck installed.
• Top Throttle installed for easier tent stake driving with less bending for the installer.
• Service Kit for general maintenance
• Powered by Honda™ GX35 4-Stroke Engine
• Shock resistant heat-treated steel components
• Double sided, sealed bearings on all rotating parts
• Equipped with Rhino’s CIS™ Vibration Dampening.
• Padded grip for handling comfort.
• Removable bottom handle.
• Made in the U.S.A.
• Rhino Lifetime Impact Warranty. See warranty statement for details.

Specifications:

Master Chuck ID	2.5” (63.5mm)
Driver Only Dimensions	11″ W x 14″ D x 23.5″ H (280 x 356 x 597 mm)
Driver Only Weight	42.2 lbs. (19.1 kg)
Engine	Honda GX35 4-stroke
BPM (beats per minute)	1720 (approximate)
Fuel	Unleaded Gas, 86 octane or higher
Fuel Capacity	0.67 qt. (0.63 ltr)
Engine Oil	SAE 10W-30
Lubricant	RHINO® Pro Series Lubricant
Shipping Weight	54.5 lbs. (25 kg)
Shipping Dimensions	30.5″ W x 15″ D x 18.25″ H (775 x 381 x 464 mm)

Applications:

Types & Sizes of Posts to be Driven (outside dimensions)	Chuck/Adapter
Tent Stake, 3/4″ to 2-1/2″	Tent Stake Chuck (Included)

If you have any questions give us a call during business hours and one of our friendly associates will be happy to assist you. 410-692-5170
