Rhino Multi-Pro XA Gas-Powered Post Driver – Heavy-Duty Engineered Unit (Model 301003)

Description

Free Shipping This item qualifies for free shipping anywhere in the continental United States.

Warranty 1 Year Warranty

Literature Owners Manual Parts Manual Spec Sheet Service Kit Instructions Gas Post Driver Selection Chart Maintenance Schedule Chart Square Chuck Install Instructions

For Professional Installers

The Multi-Pro™ XA Gas Post Driver is the most versatile driver in the Rhino™ Pro-Series line of gas post drivers. From T-post to large wood posts, the Multi-Pro™ XA can be adapted to handle a wide range of post diameters and materials without needing to change the anvil. Only a chuck change is required depending on the type of post installation.

• Comes standard with Rhino™ Extended Anvil and Longer 2.5” ID Master Chuck
• Includes Rhino™ Chuck-Lok™ 1″, 1-3/4″, 2″ Adapters
• Rhino™ Tension-Grip crankcase cover provides tool-free removal for ease of lubricant application
• Quick change chuck is designed to receive the Chuck-Lok™ Adapter System and be quickly removed when changing accessories
• Two-piece adapter design allows quick removal of driver from the post
• Equipped with Rhino’s CIS™ Vibration Dampening
• Padded grip for handling comfort
• Powered by Honda™ GX35 4-Stroke Engine
• Shock resistant heat-treated steel components
• High-grade virgin aluminum cast body
• Double sided, sealed bearings on all rotating parts
• Removable bottom handle
• Made in the U.S.A.
• Rhino Lifetime Impact Warranty. See warranty statement for details

Specifications:

Master Chuck ID	2.5” (63.5mm)
Driver Only Dimensions	11″ W x 14″ D x 28.5″ H (280 x 356 x 724 mm)
Driver Only Weight	47.25 (27.43)
Engine	Honda GX35 4-stroke
BPM (beats per minute)	1720 (approximate)
Fuel	Unleaded Gas, 86 octane or higher
Fuel Capacity	0.67 qt. (0.63 ltr)
Engine Oil	SAE 10W-30
Lubricant	Rhino® Pro Series Lubricant
Shipping Weight	55 lbs. (24.9 kg)
Shipping Dimensions	30.5″ L x 15″ W x 18.25″ H (775 x 381 x 464 mm)

Application:

Types & Sizes of Posts (outside dimensions)	Chuck/Adapter
T-Post	1-3/4” Adapter (Included)
Ground Rod, 1/2″ & 3/4″	1” Adapter (Included)
Concrete Form Pin, 1″	1” Adapter (Included)
Round Pipe, 1″ to 1-5/8″	1-3/4” Adapter (Included)
Round Pipe, 1-3/4″ to 1-7/8″	2” Adapter (Included)
Round Pipe, 2″ to 2-3/8″	Extended Master Chuck (Included)
Tent Stake, 3/4″ to 2-1/2″	Tent Stake Chuck (Optional)
Square Tube, 1-3/4″ to 2-1/2″	Square Anchor Chuck*
Channel Post, 1.2 to 4 lbs.	Slotted Chuck (Optional)
Silt Fence Post	Slotted Chuck (Optional)
Round Solid Wood Post, 3-7/8″	Adapter Plate & 4″ Chuck (Optional)
Round Solid Wood Post, 2-1/2″ to 3-3/8″	Adapter Plate & 3-1/2″ Chuck (Optional)
Square Solid Wood Post, 2″ to 2-7/8″	Adapter Plate & 3″ Square Chuck (Optional)
